LD Systems FX 300

(0)
🎧
Support online
Support 1 Support 2 Support 3
€174,00
Sis. alv.
Toimitus 10 € (Ilmainen toimitus yli 200 €)
€174,00

Kuvaus

  • Täydellinen laulaja/lauluntekijöille lavalla tai studiossa.
  • Toimii myös 2-kanavaisena mikserinä
  • Mykistystoiminto on helppo käyttää käsin tai jaloin
  • FX Mute mahdollistaa puhumisen normaalilla äänellä yleisölle.
  • Tulo dynaamiselle ja kondensaattorimikrofonille.


  • 16 digitaalista esiasetusta, 16-bittinen laatu
  • Matalan kohinan, korkean impedanssin instrumenttitulo
  • Erilliset FX-lähetykset molemmille kanaville
  • Lisää FX-silmukka instrumenttituloa varten
  • Mikrofonitulo HPF:llä ja +48 V:n phantom-teho
  • Molempien kanavien signaali/huippu LED
  • "Clip"-LED tehosteissa
  • FX MUTE pedaali efektien mykistämiseen
  • Tasapainotettu ja Tasapainoton lähtö.
  • Virtalähde: 9V paristo
  • Adapteri 9VDC / 250mA ei sisälly toimitukseen

Erityisominaisuudet

  • Weight (kg)
    1

Lisätiedot

Microphone channels


Microphone channels

1


Mic inputs

XLR/6.3 mm jack


Frequency Response Microphone Channel

50 - 20000 Hz


Amplification range Microphone channel XLR input

42 dB


Mono Mic Input Input THD-N

<0,03%


Impedance XLR input

6000 Ohm(s)


Phantom power

+48V DC to XLR Input


Microphone channel Jack input Input type

electronically balanced


Amplification range Microphone channel Jack input

20 dB


THD jack input

<0.045%


Microphone Equalizer

+5/-8dB @ 8kHz


Microphone channel controls

FX SEND , Gain , tone


Microphone Channels Display Elements

channel signal


Instrument channels


Instrument inputs

1


gain range

23 dB


THD

0.03%


Equalizer

+7/-8dB @ 10kHz


Channel Inserts

1


Controls

FX SEND , Gain , tone


Indicators

3-colour LED (SIG) , channel signal


Main Section


Line outputs

2


Line output connectors

6.3 mm TRS , XLR


Output level XLR

Max. +17dBu, balanced


Impedance XLR output

150 Ohm(s)


Output level Jack output

Max. +5dBV, unbalanced


Impedance jack output

40 Ohm(s)


Digital Effects Processor

Yes


Number of Presets

16


Main section controls

DFX Presets , FX MUTE , MIX OUT , MUTE ALL , Power


Display elements Main section

Effekt-Clip , FX MUTE , MUTE ALL , red LED (FX CLIP)


General Specifications


Operating voltage

9 V block , External mains adapter 9VDC / 250mA (not included


Ambient temperature ( in operation )

0 - 40° °C


Relative Humidity

< 80% (non-condensing)


Width

160 mm


Height

55 mm


Length

163 mm


Weight

0,65 kg


Features

Preparation for microphone stand mounting

Brand: LD Systems
SKU: LDS-LDFX300
Barcode: 4049521413667
