AX73

Features

• Two VCOs per layer
• Waveshapes: Saw, Triangle, Square, Saw + Triangle, Sine
• Pulse width assignable when using any waveshape
• Sub oscillator per VCO
• Pink noise generator per layer
• Filter per layer (LP/HP/BP) with self-oscillating capability
• OWFM feature modulates the VCF frequency using the oscillator frequency
• Stack or split Upper and Lower layers to create unique and complex patches
• Up to 24 voices of polyphony, quadrupling the original six
• MIDI Split mode allows two MIDI channels to play the Upper and Lower layers
• Assign mod wheel control to Upper, Lower or both synth layers
• Four DADSR Envelope Generators per layer (one hardwired to VCA level)
• Four LFOs per layer
• Modulation destinations: VCO, VCF, VCA level, PWM, Resonance, OWFM, Pan
• LFO shapes: Saw Up/Down, Triangle, Square, Random, Parabola Up/Down, Sine
• Envelopes can be inverted for falling pitch and filter effects
• Step function on LFOs acts like sample-and-hold operation over traditional waveshapes
• Retrigger modes on LFOs and Envelopes including Legato, Poly and other options
• Poly/Dual/Unison keyboard assign modes, with variable Detune
• Mono mode with Low/High/Last note priority
• Solo/Poly Portamento with adjustable Time
• Arpeggiator per layer with variable Rate and Hold function
• Modes: Order, Up, Down, Up/Down Incl/Excl, Alt Rise/Fall, Random, Shuffle, Improv, Chord
• Cycle arp playback through Octaves, sync to DAW tempo and choose gate Length
• Built-in Chorus with four modes of operation
• Eight ‘external’ (post synth) effect units with flexible ordering and Mix dials
• Compressor with Attack, Release, Threshold, Ratio and Makeup
• Chorus with Rate, Depth, Sync and Width
• Flanger with Rate, Depth, Sync, Feedback and Width
• Phaser with Rate, Depth, Sync, Feedback and Width
• Delay with Time, Pan (ping-pong), Tone (filter)
• Reverb with Delay, Time, Tone (filter), Damping and Width
• Distortion with Drive, Tone and Level controls
• EQ with Low, Mid and High bands; Mid band features Bandwidth control
