Kuvaus
Kuvaus
- 1 tehokas LED 7 W SMD 8072 3in1 TCL RGB
- Pyörivä animaatioratas
- Elektroninen himmennin
- Laserluokka 2M – ei vaadi erityisiä turvatoimenpiteitä tai laser-vastuuhenkilöä
- 3 integroitua show-ohjelmaa
- Laite jäähdytetään passiivisella konvektiolla
- Käyttö: Stand-alone, ääniohjattu mikrofonin kautta, master/slave-toiminto, DMX, QuickDMX USB:n kautta (valinnainen), W-DMX Wireless Solutionin kautta (USB, valinnainen), CRMX LumenRadion kautta (USB, valinnainen)
- Välkkymätön
- DMX-läpivienti jopa 32 lisä-DMX-laitteelle
- DMX-vikatila: Pidä tai pimeä
- 23° sädekulma
- Mukana kiinnitysteline
- 3-numeroinen 7-segmentti LED-näyttö
- Sopii esimerkiksi: Yökerhot, tanssikoulut, häät, gaalat, tapahtumat, juhlatilat, liikkuvat DJ:t/esiintyjät, ravintolat, baarit ja hotellit
- Erittäin hiljainen toiminta
- Asennusmahdollisuudet: Ripustettu tai jalustalla
Tekniset tiedot
Tekniset tiedot
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 20 W |
| Protection class: | Protection class I |
| Power connection: | Mains input via IEC connector (M) mounting version power supply cord with safety plug |
| Cable length: | 1,4 m |
| Fuse: | 5 x 20 mm, T 1 A fuse replaceable |
| Lamp type: | LED lamp |
| LED type: | 1 x 7 W SMD 8072 3in1 TCL RGB |
| Flash rate: | 0,5 - 20 Hz |
| Equipment: | Animation wheel rotating |
| Laser class: | 2M |
| Laser color: | R/G/B |
| Laser module: | R/G/B 193 mW |
| DMX channels: | 8 |
| DMX input: | 3-pin XLR (M) mounting version |
| DMX output: | 3-pin XLR (F) mounting version |
| Cooling: | Passive convection cooling |
| Control: | Stand-alone; sound to light via microphone; master/slave function; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional) |
| Projection: | Flicker-free |
| PWM frequency: | 23500 Hz |
| DMX features: | DMX feed-through for up to 32 further DMX devices |
| DMX fail mode: | Hold; blackout |
| Beam angle: | 23° |
| Beam angle (1/2 peak): | 23° |
| Housing color: | Black |
| Attachment system: | 3x Ø 10mm Mounting bracket |
| Display type: | 3 digit 7-segment LED display |
| USB port: | Type A |
| Material: | Aluminum |
| Dimensions: | Width: 24,0 cm Depth: 20,5 cm Height: 16,5 cm |
| Weight: | 1,62 kg |
| Noise classification: | Class 1 (very slight noise, suitable for noise-sensitive environments) |
| Power cord | |
| Cable construction: | 3 x 0,75 mm² H05VV-F |
